| CODE | WP05 | WP06 | WP08 | WP10 | WP12 | WP14 | WP17 |
| Advised pool size (m3) | 7~14 | 8~16 | 10~20 | 14~28 | 17~34 | 20~40 | 25~50 |
| Heating Performance Condition: Air 24ºC, Water 26ºC | |||||||
| Heating Capacity (KW) | 4.5 | 5.1 | 7 | 9.8 | 11.2 | 13.2 | 16.8 |
| COP | 5 | 5.15 | 5.07 | 5.08 | 5.3 | 5.35 | 5.4 |
| Heating Performance Condition: Air 15ºC, Water 26ºC | |||||||
| Heating Capacity (KW) | 3.65 | 3.9 | 5.2 | 7.6 | 8.7 | 10.2 | 13.5 |
| COP | 4.2 | 4.32 | 4 | 4.11 | 4.55 | 4.6 | 4.5 |
| Operating Air Temperature ºC | -5~43 | ||||||
| Power Supply (V/Hz) | 220-240V/1PH/50HZ | ||||||
| Rated Input Power(KW) | 0.86 | 0.99 | 1.34 | 1.95 | 2.11 | 2.47 | 3.11 |
| Rated Input Current(A) | 4.1 | 4.3 | 6.4 | 9.3 | 10.1 | 11.4 | 14.8 |
| Max Heating Current (A) | 5.8 | 5.9 | 8.9 | 12.7 | 13.1 | 14.8 | 19.2 |
| Water Flow Rate (m3/h) | 1.9 | 2.4 | 3.4 | 4.1 | 5.4 | 6 | 7.3 |
| Water Connection ( inch) | 1-1/2 | 1-1/2 | 1-1/2 | 1-1/2 | 1-1/2 | 1-1/2 | 1-1/2 |
| Sound level at 1m (dB(A)) | 49 | 53 | 59 | 58 | 52 | 53 | 57 |
| Net Dimension L*W*H(mm) | 755*258*500 | 937*286*550 | 937*286*550 | 1012*307*614 | 1012*307*614 | 1012*307*614 | 1117*396*703 |
| Qty per 20ft/40HQ(PCS) | 176/445 | 128/264 | 128/264 | 90/248 | 90/248 | 90/248 | 42/132 |
| CODE | WP17T | WP21 | WP26 | WP31 |
| Advised pool size (m3) | 25~55 | 30~60 | 35~70 | 45~90 |
| Heating Performance Condition: Air 24ºC, Water 26ºC | ||||
| Heating Capacity (KW) | 17.4 | 20.2 | 24.3 | 30 |
| COP | 5.84 | 5.98 | 5.69 | 5.71 |
| Heating Performance Condition: Air 15ºC, Water 26ºC | ||||
| Heating Capacity (KW) | 13.9 | 17.5 | 19.8 | 23.5 |
| COP | 4.79 | 4.75 | 4.66 | 4.77 |
| Operating Air Temperature ºC | -5~43 | |||
| Power Supply (V/Hz) | 380V/3PH/50HZ | |||
| Rated Input Power(KW) | 2.9 | 3.26 | 4.01 | 5.25 |
| Rated Input Current(A) | 5.2 | 5.8 | 7.2 | 8.8 |
| Max Heating Current (A) | 6.8 | 7.7 | 9.8 | 12 |
| Water Flow Rate (m3/h) | 7.3 | 9 | 11.2 | 13.3 |
| Water Connection ( inch) | 1-1/2 | 1-1/2 | 1-1/2 | 1-1/2 |
| Sound level at 1m (dB(A)) | 57 | 57 | 60 | 60 |
| Net Dimension L*W*H(mm) | 1117*396*703 | 1117*396*1053 | 1117*396*1053 | 1117*396*1053 |
| Qty per 20ft/40HQ(PCS) | 42/132 | 42/88 | 42/88 | 42/88 |
|
|
| CODE | WP05 | WP06 | WP08 | WP10 | WP12 | WP14 | WP17 |
| Advised pool size (m3) | 7~14 | 8~16 | 10~20 | 14~28 | 17~34 | 20~40 | 25~50 |
| Heating Performance Condition: Air 24ºC, Water 26ºC | |||||||
| Heating Capacity (KW) | 4.5 | 5.1 | 7 | 9.8 | 11.2 | 13.2 | 16.8 |
| COP | 5 | 5.15 | 5.07 | 5.08 | 5.3 | 5.35 | 5.4 |
| Heating Performance Condition: Air 15ºC, Water 26ºC | |||||||
| Heating Capacity (KW) | 3.65 | 3.9 | 5.2 | 7.6 | 8.7 | 10.2 | 13.5 |
| COP | 4.2 | 4.32 | 4 | 4.11 | 4.55 | 4.6 | 4.5 |
| Operating Air Temperature ºC | -5~43 | ||||||
| Power Supply (V/Hz) | 220-240V/1PH/50HZ | ||||||
| Rated Input Power(KW) | 0.86 | 0.99 | 1.34 | 1.95 | 2.11 | 2.47 | 3.11 |
| Rated Input Current(A) | 4.1 | 4.3 | 6.4 | 9.3 | 10.1 | 11.4 | 14.8 |
| Max Heating Current (A) | 5.8 | 5.9 | 8.9 | 12.7 | 13.1 | 14.8 | 19.2 |
| Water Flow Rate (m3/h) | 1.9 | 2.4 | 3.4 | 4.1 | 5.4 | 6 | 7.3 |
| Water Connection ( inch) | 1-1/2 | 1-1/2 | 1-1/2 | 1-1/2 | 1-1/2 | 1-1/2 | 1-1/2 |
| Sound level at 1m (dB(A)) | 49 | 53 | 59 | 58 | 52 | 53 | 57 |
| Net Dimension L*W*H(mm) | 755*258*500 | 937*286*550 | 937*286*550 | 1012*307*614 | 1012*307*614 | 1012*307*614 | 1117*396*703 |
| Qty per 20ft/40HQ(PCS) | 176/445 | 128/264 | 128/264 | 90/248 | 90/248 | 90/248 | 42/132 |
| CODE | WP17T | WP21 | WP26 | WP31 |
| Advised pool size (m3) | 25~55 | 30~60 | 35~70 | 45~90 |
| Heating Performance Condition: Air 24ºC, Water 26ºC | ||||
| Heating Capacity (KW) | 17.4 | 20.2 | 24.3 | 30 |
| COP | 5.84 | 5.98 | 5.69 | 5.71 |
| Heating Performance Condition: Air 15ºC, Water 26ºC | ||||
| Heating Capacity (KW) | 13.9 | 17.5 | 19.8 | 23.5 |
| COP | 4.79 | 4.75 | 4.66 | 4.77 |
| Operating Air Temperature ºC | -5~43 | |||
| Power Supply (V/Hz) | 380V/3PH/50HZ | |||
| Rated Input Power(KW) | 2.9 | 3.26 | 4.01 | 5.25 |
| Rated Input Current(A) | 5.2 | 5.8 | 7.2 | 8.8 |
| Max Heating Current (A) | 6.8 | 7.7 | 9.8 | 12 |
| Water Flow Rate (m3/h) | 7.3 | 9 | 11.2 | 13.3 |
| Water Connection ( inch) | 1-1/2 | 1-1/2 | 1-1/2 | 1-1/2 |
| Sound level at 1m (dB(A)) | 57 | 57 | 60 | 60 |
| Net Dimension L*W*H(mm) | 1117*396*703 | 1117*396*1053 | 1117*396*1053 | 1117*396*1053 |
| Qty per 20ft/40HQ(PCS) | 42/132 | 42/88 | 42/88 | 42/88 |
